TP48 range

The TP48 surge protection device safeguards field-mounted process transmitters where it matters, right at the unit. After a simple installation (the TP48 screws into an unused conduit entry, with no additional modification)

The TP48 surge protection device safeguards field-mounted process transmitters where it matters, right at the unit. After a simple installation (the TP48 screws into an unused conduit entry, with no additional modification), it provides high-level protection against surges and transients whilst normal operation remains unaffected. The TP48 resets itself automatically after each operation. The TP48 is available with screw threads to suit different transmitters, with explosion proof and intrinsically safe options for hazardous areas. Working voltage is 48V dc maximum with impulse ratings of 10kA peak current and 10kV peak voltage.

  • Easy and direct mounting - simply screws into spare conduit entry
  • Intrinsically safe and flameproof (explosion proof) approved versions
  • Range of thread types available
  • Fieldbus compatible
  • Available in 2, 3 & 4 wire versions
  • 10 Year ‘No Fuss’ Warranty

    Đại lý EATON Việt Nam

    Đại lý MTL Việt Nam

    Thiết bị chống sét MTL Việt Nam

Bạn quan tâm đển sản phẩm này ?

Product Code Description Downloads

intrinsically safe logo Symbol denotes that the equipment is suitable for use in hazardous area applications.
fsm logo Symbol denotes that the product has been assessed for functional safety applications

TP48    Surge protection for field transmitters Datasheet  Manual  Safety Manual

TP48-N Non-certified SPD - 1/2” NPT thread
TP48-I Non-certified SPD - 20mm ISO thread
TP48-G Non-certified SPD - G 1/2” (BSP 1/2 inch)
TP48-3-N Non-certified SPD - 1/2” NPT thread
TP48-3-I Non-certified SPD - 20mm ISO thread
TP48-3-G Non-certified SPD - G 1/2” BSP 1/2 inch
TP48-4-N Non-certified SPD - 1/2” NPT thread
TP48-4-I Non-certified SPD - 20mm ISO thread
TP48-4-G Non-certified SPD - G 1/2” BSP 1/2 inch
TO ORDER SPECIFY -
TP48-N-NDI Certified SPD - 1/2” NPT thread
TP48-I-NDI Certified SPD - 20mm ISO thread
TP48-G-NDI Certified SPD - G 1/2” (BSP 1/2 inch)
TP48-3-N-NDI Certified SPD - 1/2” NPT thread
TP48-3-I-NDI Certified SPD - 20mm ISO thread
TP48-3-G-NDI Certified SPD - 20mm ISO thread
TP48-4-N-NDI Certified SPD - 1/2” NPT thread
TP48-4-I-NDI Certified SPD - 20mm ISO thread
TP48-4-G-NDI Certified SPD - G 1/2” - BSP 1/2 inch
